Specs
18" .325", 1,3 mm, H30, SN,FA saw RTLBx SKU: 970 61 23‑38 | |
---|---|
Engine | 18" .325", 1,3 mm, H30, SN,FA saw RTLBx SKU: 970 61 23‑38 |
Chain speed at max power | 56.76 fts |
Cylinder displacement | 40.9 cm³ |
Output shaft power1 | 2.4 hp |
Torque, max. | 2.16 Nm |
Torque, max. at rpm | 6,300 rpm |
Clutch engagement speed (±120) | 4,300 rpm |
Electrode gap | 0.02 in |
Idling speed | 2,900 rpm |
Ignition module air gap | 0.01 in |
Maximum power speed | 9,000 rpm |
Oil pump type | Fixed flow |
Equipment | |
Recommended bar length, min | 13 in |
Pitch | .325" |
Recommended bar length, max | 18 in |
Chain type | H30 |
Bar length | 45 cm |
Bar length (inch) | 18 in |
Sprocket type | Spur 7 |
Gauge | .050" |
Dimensions | |
Weight (excl. cutting equipment) | 9.78 lbs |
Sound and noise | |
Sound pressure level at operators ear | 102 dB(A) |
Sound power level, guaranteed (LWA) | 114 dB(A) |
Sound power level, measured | 112 dB(A) |
Vibration | |
Equivalent vibration level (ahv, eq) rear handle | 4.2 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.8 m/s² |
Lubricant | |
Oil tank volume | 0.53 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Emission | |
Exhaust emissions (CO₂ EU V)2 | 813 g/kWh |
