Specs
T45X , Multi 300-3, Scarlett 200-22, USSKU: 967 63 79‑05 | |
|---|---|
| Engine | T45X , Multi 300-3, Scarlett 200-22, US SKU: 967 63 79‑05 |
| Torque, max. | 2.6 Nm |
| Torque, max. at rpm | 6,000 rpm |
| Cylinder displacement | 2.8 cu.inch |
| Power output | 2.8 hp |
| Maximum power speed | 9,000 rpm |
| Fuel tank volume | 30.43 fl oz |
| Fuel consumption | 450 g/kWh |
| Idling speed | 2,700 rpm |
| Electrode gap | 0.02 in |
| Clutch engagement speed (±120) | 3,900 rpm |
| Maximum rpm output shaft | 8,800 rpm |
| Output shaft thread | M12x1.75V |
| Transmission | |
| Gear ratio | 1.4 |
| Drive gear angle | 35 ° |
| Dimensions | |
| Weight (excl. cutting equipment) | 19.2 lbs |
| Tube length | 54.488 in |
| Tube diameter | 1.3 in |
| Equipment | |
| Grass blade | Multi 300-3 |
| Harness | Balance X |
| Trimmer head | T45X M12 |
| Saw blade | Scarlett 200-22 |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Lubricant type (bevel gear) | Biodegradable grease |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 117 dB(A) |
| Sound power level, measured | 115 dB(A) |
| Sound pressure level at operators ear | 100 dB(A) |
| Emission | |
| Exhaust emissions (HC average) | 36.45 g/kWh |
| Exhaust emissions (HC average) | 35.37 g/kWh |
| Exhaust emissions (CO average) | 262.85 g/kWh |
| Exhaust emissions (CO average) | 269.16 g/kWh |
| Exhaust emissions (NOx average) | 1.96 g/kWh |
| Exhaust emissions (NOx average) | 1.76 g/kWh |
