Specs
Dimensions and Weights
- Transport Height 61 in 154.9 cm
- Transport Width - ends up 12 ft 3.7 m
- Transport Width - ends down 12.7 ft 3.9 m
- Transport Length 18.2 ft 5.5 m
- Cutting Width 12 ft 3.7 m
- Working Height 61 in 154.9 cm
- Working Width 12.8 ft 3.9 m
- Working Length 17.2 ft 5.2 m
- Mower swung out offset 50 in 127 cm
- Cutter bar lift height clearance 16 in 40.6 cm
- Total Weight 3500 lbs 1587.6 kg
- Tongue Weight 1200 lbs 544.3 kg
- Suspension Hydraulic
- Torque Protection Driveline: friction disc clutch
- Tires 31x13.5-15
Tractor Requirements
- Tongue/hitch Drawbar with swivel gearbox, OR 2-point with swivel gearbox, category II or III N
- Drive PTO 540 rpm
- PTO horsepower recommended 65 hp 48.5 kw
- Hydraulic Type 2 remote, single-acting lift, double-acting swing
- Hydraulic Pressure 1900 psi 131 bar
- Hydraulic flow rate 6 gpm 22.7 L/min
Cutter bar
- Cutter bar type Q3®
- Cut height 1 in - 3 in (2.5 cm - 7.6 cm)
- Number of Discs 8
- Disc Diameter 23 in 58.4 cm
- Disc Speed 2700 rpm
- Number of Blades 16
- Angle Adjustment Hydraulic pitch control
- Quick Clip® blade retention system Standard
- Quick-Change™ shear ring Standard
- Curtain material 1400 g/m2 polyester woven material with flexible PVC covering
- 3-year limited cutter bar warranty Standard
Features
- Optional swath formation Optional right crop divider, standard right swath wheel
- Skid Shoes Standard modular independent skid shoes; Optional topping shoes and wear skids
- Highway Lights Standard
