Vermeer TM1410 Trailed Mower

Contact us for price

Stock status: Call Store for Availability

With a cutting width of 20.8 ft (6.3 m), the TM1410 trailed mower is the largest trailed mower in our fleet made for large haymaking operations that need to maximize productivity in the field. It’s big on convenience, too. Operating, transporting and maintaining a large pull-behind mower should always be this simple. The big question: How does it mow? With smart features like a nitrogen-charged accumulator suspension system, it delivers a consistent, clean cut as you cover more acres in a day.

Call Us Now

Specs

  • Dimensions and Weights

    • Transport Height 76 in 193 cm
    • Transport width - standard 9.1 ft 2.8 m
    • Transport width with flotation tires 9.8 ft 3 m
    • Transport Length 25.2 ft 7.7 m
    • Cutting Width 20.8 ft 6.3 m
    • Working Height 76 in 193 cm
    • Working Width 27.1 ft 8.3 m
    • Working Length 19.8 ft 6 m
    • Total Weight 6660 lbs 3020.9 kg
    • Tongue Weight 1940 lbs 880 kg
    • Suspension Hydraulic
    • Torque Protection Driveline: friction disc clutch
    • Tires Standard 31x13.5-15; Optional 480/45x17 flotation tire
  • Tractor Requirements

    • Tongue/hitch 2-point quick hitch with swivel gearbox, category II or III N
    • Drive PTO 1000 rpm
    • PTO horsepower recommended 105 hp 78.3 kw
    • Hydraulic Type 3 double-acting (2 double-acting with optional kit)
    • Hydraulic Pressure 1850 psi 127.6 bar
    • Hydraulic flow rate 6 gpm 22.7 L/min
  • Cutter bar

    • Cutter bar type Q3®
    • Cut height 1 in - 3 in (2.5 cm - 7.6 cm)
    • Number of Discs 14
    • Disc Diameter 23 in 58.4 cm
    • Disc Speed 2690 rpm
    • Number of Blades 28
    • Angle Adjustment Hydraulic pitch control
    • Quick Clip® blade retention system Standard
    • Quick-Change™ shear ring Standard
    • Curtain material 1400 g/m2 polyester woven material with flexible PVC covering
    • 3-year limited cutter bar warranty Standard
  • Features

    • Optional swath formation Optional swathwheel
    • Skid Shoes Standard modular independent skid shoes; Optional topping wear skids
    • Highway Lights Standard
