Specs
Bale Size
- Bale Diameter 36 in - 72 in (91.4 cm - 182.9 cm)
- Bale Width 61 in 154.9 cm
- Maximum bale weight 2400 lbs 1088.6 kg
Dimensions and Weights
- Length with Netwrap and Ramp 248 in 629.9 cm
- Height 124 in 315 cm
- Width 142 in 360.7 cm
- Weight 19500 lbs 8845.1 kg
Engine
- Engine 200 hp (149 kW) Cummins Stage V 4.5L engine
- Ground Drive 2-speed
- Maximum Road Speed 30+ mph (48.3+ kph)
- Maximum Baling Speed 12 mph 19.3 km/h
- Rear Tire 18.4 R38
- Front Tire 21.5L 16.1 HWY
- Fuel Capacity 88 gal 333.1 L
- DEF Capacity 8.8 gal 33.3 L
- Suspension Double A-arm independent hydraulic
- Dual steering mode Standard
- Counter steer Standard
Control system
- Display 10.4-in (26.4-cm) color touchscreen with soft keys
- Bale shape sensors Standard
- Real-time moisture data Standard
- Scales Standard
- Field Statistics 50 fields with names
- Automation mode Standard
- LED work lights Standard
Cab
- Seats Leather, heated, air-conditioned, air-ride, adjustable
- Entertainment AM/FM bluetooth with auxiliary input
- Steering Tilt and telescoping
- Camera Two infrared cameras: one pickup view and one tailgate view with auto-changing color display
- Instructional seat Standard
- Beverage cooler Standard
- In-cab heat Standard
- In-cab air conditioning Standard
Bale Forming Chamber
- Drive roller size 5.5 in 14 cm
- Drum roller size 12 in 30.5 cm
- Idler roller size 3.5 in (8.9 cm), 4.8 in (12.1 cm), 5.5 in (14 cm)
- Start Roller Size 4.5 in 11.4 cm
- Belt Type Standard mini rough top
- Number of Belts 8
- Width of Belt 6.8 in 17.3 cm
- Length of belt (long) 540 in 1371.6 cm
- Length of belt (short) 533 in 1353.8 cm
- Type of Lace Alligator rivet
- Silage kit Optional
- Powered windguard Optional
