Woods TBW17.40

Contact us for price

Stock status: Call Store for Availability


#1 In Cut Quality

Every Turf Batwing® features the best-in-class cutting technology of the TurfKeeper® Series verified by independent testing.
Read Cut Quality Study.

Faster Finish Results

High blade tip speeds and a high-torque belt design let you mow faster while maintaining superior cut quality.

Unmatched Gearbox PROTECTION

10-year warranty including parts, labor, and seals.

Call Us Now


Product Tier Professional
Tractor PTO 540 rpm (HP) 40-80
Hitch CAT 2, Drawbar
Hitch Adjustment Floating clevis, multi-position
Cutting Width (in) 204
Cutting Height (in) 1.5 – 5.5
Deck Cut Widths (in) Wing Deck 72 / Center Deck 72
Deck Overlap (in) 6
Blade Tip Speed (fpm) 18,100
Blade Spindle Bearings Triple ball bearings
Overall Wt. / Transport Tongue Wt. (lbs) 3569 / 794
Transport H x L x W (in) 90.7 x 176 x 101
Transport Tires (in) (2) 20.5 x 8-10
Caster Wheels (in) (10) 18 x 9.5-8 pneumatic
Gearbox Rating (HP) 100 splitter / 75 deck
Drive Type Gearbox over v-belt
Drivelines Main CAT 4 (CV) / Wing CAT 3
Caster Wheel Bearings Tapered roller bearings
Wing Deck Lift Cylinders 3 x 10 single-acting
Center Deck Lift Cylinders 3 x 8 single-acting
Trailer Frame Construction 4.0 x 4.0 x .25 square tube
Deck Thickness (in) 0.188
Blade Spindles (9) ductile iron
Blade Dimensions (in) (9) .25 x 2.5 x 25
Transport Lock Automatic, manual release
Transport Tires Highway speed-rated
Cut Height Adjustment Spacer on caster
Caster Pivot Bushings Yes
Belt Construction HB-section, Aramid
Belt Adjustment Spring-loaded idler w/bearing pivot
Light Kit Standard
Hydraulic Remotes Required 1
Hydraulic Wing Unlock Optional
Warranty Spindle/Gearbox 10-Mar
Woods C® Compact/Subcompact
Structure Warranty 2 years
