Specs
Engine
- Model
- 4TNV88C-NKAH
- 4TNV88C-NKAH
- Output
- 39 HP / 2,500 rpm
- 29.1 kw / 2,500 rpm
- Displacement
- 133.6 in³
- 2.189 cm³
- Type
- Water-cooled 4-cylinder diesel
- Water-cooled 4-cylinder diesel
Performance
- Standard Bucket Capacity
- 0.65 yd³
- 0.5 m³
- Operating Load
- 2,535 lbs
- 11.2 kN
- Lifting Capacity at Low End
- 7,451 lbs
- 33.1 kN
- Tipping Load – Straight
- 6,070 lbs
- 27 kN
- Tipping Load, Articulated
- 5,058 lbs
- 22.5 kN
- Breakout Force
- 6,085 lbs
- 27.1 kN
- Dumping Clearance
- 7’11”
- 2,420 mm
- Traveling Speed
- 11.8 mph
- 19.0 km/h
- Oscillation Angle
- ±8 deg
- ±8 deg
- Minimum Turning Radius
- 12’6″
- 3,810 mm
- Min. Ground Clearance
- 1’3″
- 370 mm
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
This div for css purpose only
PTO
- Front Hyd. PTO
- 3,000 PSI
- 20590 kPa
- Front Hyd. PTO
- 14.8 GPM
- 56.0 L/min
Steering
- Articulate Angle
- 40.5 deg
- 40.5 deg
- Type
- Center-Pivot Frame Articulation w/Full Hyd. Power
- Center-Pivot Frame Articulation w/Full Hyd. Power
Transmission
- Type
- Automatic Hydrostatic
- Automatic Hydrostatic
This div for css purpose only
Drives
- Type
- 4-Wheel Drive
- 4-Wheel Drive
This div for css purpose only
Brakes
- Type
- Fully Enclosed, Mechanical, Wet, Multiple Disc
- Fully Enclosed, Mechanical, Wet, Multiple Disc
This div for css purpose only
Operating Weight
- Canopy
- 7,848 lbs
- 3,560 kg
- Cabin
- 8,422 lbs
- 3,820 kg
Transport Dimensions
- L x W x H
- 14’6″ x 5’7″ x 8’5″
- 4,425mm x 1,690mm x 2,555mm
