Specs
T35X narrow guard. Scaper handles, US/CASKU: 970 44 65‑03 | |
|---|---|
| Capacity | T35X narrow guard. Scaper handles, US/CA SKU: 970 44 65‑03 |
| Cutting width | 19.3 in |
| Dimensions | |
| Weight (excl. cutting equipment) | 10.36 lbs |
| Product size length | 70.43 in |
| Product size width | 9.53 in |
| Tube length | 58.386 in |
| Product size height | 8.98 in |
| Tube diameter | 0.94 in |
| Engine | |
| Cylinder displacement | 1.55 cu.inch |
| Power output | 1.34 hp |
| Maximum power speed | 8,500 rpm |
| Fuel tank volume | 21.98 fl oz |
| Fuel consumption | 600 g/kWh |
| Idling speed | 3,000 rpm |
| Spark plug | Husqvarna HQT-2 |
| Electrode gap | 0.03 in |
| Torque, max. at rpm | 6,000 rpm |
| Torque, max. | 1.2 Nm |
| Clutch engagement speed (±120) | 4,000 rpm |
| Maximum rpm output shaft | 5,500 rpm |
| Equipment | |
| Trimmer head | T35X M10 |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Sound and Noise | |
| Sound pressure level at operators ear | 98 dB(A) |
| Sound power level, guaranteed (LWA) | 114 dB(A) |
| Transmission | |
| Gear ratio | 23 |
| Drive gear angle | 30 ° |
