Specs
Dimensions and Weights
- Loading height - standard 110 in 279.4 cm
- Machine weight - standard 9560 lbs 4336.3 kg
- Maximum net load 14000 lbs 6350.3 kg
- Total length 211 in 535.9 cm
- Transport width - 50-in folding conveyor extension 117 in 297.2 cm
- Working width - 50-in folding conveyor extension 135 in 342.9 cm
- Tires (retread) Standard 445/50R-22.5; Optional 445/50R-22.5 lug; Optional 255/70R-22.5 dual
Tub and screws
- Capacity 420 cu ft 11.9 cu m
- Number of screws 1
- Number of knives per screw 6
- Tub wall thickness 1/4 in (6.4 mm)
- Tub wall material AR200
- Floor thickness 3/4 in (19.1 mm)
- Screw flighting thickness 5/8 in (15.9 mm)
- Screw flighting material AR200
Discharge System
- Discharge style Front conveyor
- Discharge Direction Left or right
- Folding conveyor extension length 25 in/40 in/50 in (64 cm/100 cm/130 cm)
- Bi-directional conveyor length 101 in/110 in/119 in (257 cm/280 cm/302 cm) OR 101 in (257 cm) hydraulic shift
Tractor Requirements
- Minimum PTO horsepower 100 hp (75 kW)
- Recommended PTO horsepower 120 hp 89.5 kw
Drive System
- Driveline Standard: 1,000 rpm, CV; Optional: 540 rpm, CV
- Two-speed gearbox Optional
- Torque Protection Shear bolt
- Screw rpm 39 (1-speed); 39/26 (2-speed)
Scale system
- Scale display Digi-Star EZ2810-BT
- Number of weigh bars 4
- Bluetooth connectivity Standard
